STATCLAVE G4
STATCLAVE G4
SKU:STATCLAVE-G4
Regular price
$8,245.00
Regular price
Sale price
$8,245.00
Unit price
per
SciCan STATCLAVE is a Class B vacuum sterilizer that incorporates both pre-sterilization vacuum to improve steam penetration and post-sterilization vacuum to improve drying. Its 11” chamber and vacuum-assisted closed-door drying efficiently delivers sterilized and dried wrapped instruments.
Chamber Dimensions: 11”x15”
Overall Dimensions: 25”x17.75”x19.5”
- Fast - SciCan STATCLAVEcan efficiently sterilize and dry wrapped instrument loads in as little as 38 minutes. (Results based on testing with a 3.5 lbs/1.59 kg load.)
- Dry - Closed-door drying and vacuum technology results in perfectly dried instruments every time.
- Capacity - SciCan STATCLAVE’s 11” chamber can sterilize up to 4 full-size cassettes and 4 exam cassettes or up to 20 pouches with included pouch racks.
- G4 Technology SciCan’s G4 equipment can connect and send information to your smart devices so you can have cycle data, instructions, and maintenance notifications at your fingertips.
- Gentle - Fresh water is used in every cycle, reducing the buildup of oils and debris.
- Versatile - SciCan STATCLAVEoffers a number of filling & draining options, including easily accessible and cleanable top reservoirs, front manual fill and a rear automatic fill option that can be connected to the VistaPure water filtration system for automated filling.
Cycle Times and Maximum Load Weights (120v):
Cycles | Temperature / Time | Cycle Times* | Maximum Load Weight |
STATCLAVE?G4 | |||
---|---|---|---|
Solid Unwrapped | 270F (132C) / 4 mins | 18 mins | 13.2 lbs (6 kg) |
Solid Wrapped | 270F (132C) / 4 mins | 44 mins | 13.2 lbs (6 kg) |
Hollow Unwrapped | 270F (132C) / 4 mins | 23 mins | 13.2 lbs (6 kg) |
Hollow Wrapped | 270F (132C) / 4 mins | 50 mins | 13.2 lbs (6 kg) |
Textiles/Porous | 270F (132C) / 4 mins | 49 mins | 4.4 lbs (2 kg) |
Rubber & Plastic | 250F (121C) / 20 mins | 36 mins | 4.4 lbs (2 kg) |
Unit Specifications:
STATCLAVE?G4 | |
---|---|
Unit size (L x W x H) | 25" x 17.75" x 19.5" / 635 x 450 x 495mm |
Volume | 6.87 gal (26 L) |
Chamber Dimensions (D x L) | 11" diameter, 15" depth / 297 x 381mm |
Weight | 61.6 kg (135.8 lbs) (without water and packaging) |
Voltage | 120V, 60Hz, 12 A |
